Code | Каталожный номер | Qty | Part name | Applied S/N range | ICA | В корзину |
1 | 8972490840 | 1 | PUMP ASM; INJ | 199912- | |
15 | 8972475920 | 1 | COUPLING ASM; INJ PUMP | 200001- | |
16 | 8970314672 | 1 | PIPE; INJ NO.1 | 198911- | |
17 | 8970314682 | 1 | PIPE; INJ NO.2 | 198911- | |
18 | 8970314692 | 1 | PIPE; INJ NO.3 | 198911- | |
19 | 8970314702 | 1 | PIPE; INJ NO.4 | 198911- | |
031(B) | 8972221700 | 4 | NOZZLE ASM; INJ | 198911- | |
032(B) | 8971348410 | 4 | HOLDER ASM; NOZZLE | 198911- | |
33 | 1153113010 | 4 | NOZZLE; INJ | 198911- | |
34 | 1096750371 | 4 | BOLT; EYE,NOZZLE HOLDER | 198911- | |
35 | 1153320170 | 4 | NUT; NOZZLE RET,NOZZLE HOLDER | 198911- | |
36 | 1096300820 | 8 | GASKET; RETURN PIPE,NOZZLE HOLDER | 198911- | |
037(B) | 5153320060 | 4 | NUT; CAP,NOZZLE HOLDER | 198911- | |
038(B) | 5153390600 | 4 | GASKET; CAP NUT,NOZZLE HOLDER | 198911- | |
039(B) | 8941695030 | 4 | SCREW; ADJ,NOZZLE SPRING,NOZZLE HOLDER | 198911- | |
041(B) | 8943203080 | 4 | CONNECTOR; FUEL INL,NOZZLE HOLDER | 198911- | |
42 | 5513390030 | 4 | GASKET; INL CONNECTOR,NOZZLE HOLDER | 198911- | |
44 | 5153430050 | 4 | SPRING; NOZZLE,NOZZLE HOLDER | 198911- | |
045(B) | 8941695020 | 4 | ROD; PUSH,NOZZLE HOLDER | 198911- | |
54 | 9153390510 | 4 | COVER; DUST,NOZZLE HOLDER | 198911- | |
62 | 911501080 | 8 | NUT; NOZZLE HOLDER | 198911-200602 | A |
62 | 911801080 | 8 | NUT; NOZZLE HOLDER | 200603- | |
063(B) | 8970209371 | 1 | PIPE; FUEL,NOZZLE LEAK OFF | 198911- | |
65 | 9095720140 | 4 | GASKET; FUEL FILTER | 198911- | |
66 | 5153150030 | 4 | GASKET; INJ NOZZLE | 198911- | |
72 | 280510200 | 1 | BOLT; BRKT TO INJ PUMP | 199912- | |
73 | 9091505100 | 1 | WASHER; LK,BRKT TO INJ PUMP | 199912-200107 | |
080(C) | 8972221710 | 1 | BRACKET; PUMP | 198911-200501 | |
080(C) | 8973227300 | 1 | BRACKET; PUMP | 200502- | |
84 | 9091105100 | 1 | NUT; BRKT TO BRKT | 198911-200107 | |
84 | 911502100 | 1 | NUT; BRKT TO BRKT | 200108-200602 | A |
84 | 911802100 | 1 | NUT; BRKT TO BRKT | 200603- | |
87 | 280810200 | 2 | BOLT; PUMP | 199904-200512 | A |
87 | 9153390511 | 2 | BOLT; PUMP | 200601- | |
93 | 9095714080 | 2 | GASKET; LEAK OFF PIPE | 198911- | |
113 | 5154190131 | 3 | CLIP; INJ PIPE | 198911- | |
133(A) | 8972572570 | 1 | PIPE; INJ NOZZLE LEAK OFF | 199908- | |
134 | 9153390512 | 1 | BOLT; JOINT,LEAK OFF PIPE | 198911- | |
137(A) | 5154112231 | 1 | PIPE ASM; LEAK OFF | 198911- | |
