Code | Каталожный номер | Qty | Part name | Applied S/N range | ICA | В корзину |
2 | 8972266540 | 1 | CASE; PINION,STARTER | 198911- | ||
3 | 1811295180 | 1 | METAL; PINION CASE STAR | 198911- | ||
10 | 1811291810 | 1 | SHAFT; GEAR STARTER | 198911- | ||
16 | 1811210250 | 1 | ARMATURE; STARTER | 198911- | ||
017(A) | 5811292700 | 1 | BEARING; ARMATURE,START | 198911- | ||
017(B) | 5811292690 | 1 | BEARING; ARMATURE,START | 198911- | ||
18 | 1811211750 | 1 | WASHER; THRUST,ARMATURE | 198911- | ||
19 | 8972266490 | 1 | COIL; FIELD,STARTER | 198911-200002 | ||
19 | 8972505740 | 1 | COIL; FIELD,STARTER | 200003- | ||
20 | 1811160240 | 2 | BRUSH; (+),STARTER | 198911-200002 | ||
20 | 1811160720 | 2 | BRUSH; (+),STARTER | 200003- | ||
21 | 1811291780 | 4 | SPRING; BRUSH HOLDER ST | 198911- | ||
22 | 1811180210 | 1 | HOLDER; BRUSH STARTER | 198911-200002 | ||
22 | 1811180650 | 1 | HOLDER; BRUSH STARTER | 200003- | ||
23 | 8972266500 | 1 | COVER; RR COVER STARTER | 198911- | ||
027(B) | 8970304040 | 2 | BOLT; THROUGH,STARTER | 198911- | ||
28 | 5811270130 | 1 | LEVER; SHIFT,STARTER | 198911- | ||
31 | 8972266530 | 1 | SWITCH; ENGAGE STARTER | 198911- | ||
50 | 1811160230 | 2 | BRUSH; (-),STARTER | 198911-200002 | ||
50 | 8972505741 | 2 | BRUSH; (-),STARTER | 200003- | ||
54 | 1811230096 | 1 | CLUTCH; PINION,STARTER | 198911- | ||
67 | 8972266510 | 1 | BEARING; CENTER,STARTER | 198911- | ||
73 | 1811291760 | 1 | STOPPER SET; PINION | 198911- | ||
082(A) | 1811291820 | 1 | COVER; DUST ENGAGE SW S | 198911- | ||
86 | 8972266550 | 1 | RELAY; STARTER | 199504-200002 | ||
86 | 8972567160 | 1 | RELAY; STARTER | 200003- | ||
90 | 1811291800 | 1 | GASKET; ARMATURE | 198911- | ||
93 | 8972266520 | 1 | SEAL; OIL,CENTER BEARING,STARTER | 198911- |
