| Code | Каталожный номер | Qty | Part name | Applied S/N range | ICA | В корзину |
| 1(A) | 1136108570 | 1 | PUMP ASM; WATER,W/GASKET | 198802 - 198905 | ||
| 1(A) | 1136500991 | 1 | PUMP ASM; WATER,W/GASKET | 198906 - 199807 | ||
| 1(A) | 1136500991 | 1 | PUMP ASM; WATER,W/GASKET | 199808 - | ||
| 2(A) | 1136106891 | 1 | PUMP ASM; WATER | 198308 - 198905 | ||
| 2(A) | 1136108921 | 1 | PUMP ASM; WATER | 198906 - 199807 | ||
| 2(A) | 1136108921 | 1 | PUMP ASM; WATER | 199808 - | ||
| 3 | 1136140080 | 1 | GASKET; PUMP TO C/BL | 198308 - 198906 | A | |
| 3 | 1117790140 | 1 | GASKET; PUMP TO C/BL | 198907 - 199506 | ||
| 3 | 1136140140 | 1 | GASKET; PUMP TO C/BL | 199507 - | ||
| 4(A) | 1878106632 | 1 | REPAIR KIT; WATER PUMP | 198802 - 200009 | ||
| 4(C) | 1878121230 | 1 | REPAIR KIT; WATER PUMP | 200010 - | ||
| 6 | 1095030160 | 1 | WASHER; PL,PULLEY | 198308 - 199807 | ||
| 6 | 1095030160 | 1 | WASHER; PL,PULLEY | 199808 - | ||
| 7(A) | 1136411380 | 1 | PULLEY; WATER PUMP | 198308 - 198905 | ||
| 7(B) | 1136411500 | 1 | PULLEY; WATER PUMP | 198906 - | ||
| 9 | 9091801720 | 1 | RING; SNAP,WATER PUMP | 198308 - | ||
| 11 | 1136340190 | 1 | SPACER; BRG,WATER PUMP | 198308 - | ||
| 18 | 1136210260 | 1 | IMPELLER; WATER PUMP | 198308 - 200009 | ||
| 18 | 1136210630 | 1 | IMPELLER; WATER PUMP | 200010 - | ||
| 19 | 1136130420 | 1 | GASKET; COVER TO BODY | 198802 - | ||
| 20 | 1136120320 | 1 | COVER; WATER PUMP | 198802 - | ||
| 24 | 9016562650 | 2 | BOLT; WATER PUMP | 198308 - 199003 | A | |
| 24 | 0168062650 | 2 | BOLT; WATER PUMP | 199004 - | ||
| 24 | 9016562600 | 3 | BOLT; WATER PUMP | 198308 - 199003 | A | |
| 24 | 0168062600 | 3 | BOLT; WATER PUMP | 199004 - | ||
| 26(A) | 1136390060 | 1 | COVER; DUST,WATER PUMP | 198308 - 199807 | ||
| 26(A) | 1136390060 | 1 | COVER; DUST,WATER PUMP | 199808 - | ||
| 26(C) | 1136390070 | 1 | COVER; DUST,WATER PUMP | 198308 - 199807 | ||
| 26(C) | 1136390070 | 1 | COVER; DUST,WATER PUMP | 199808 - | ||
| 27(A) | 1098001770 | 2 | BEARING; WATER PUMP | 198511 - 199807 | ||
| 27(A) | 1098001770 | 2 | BEARING; WATER PUMP | 199808 - | ||
| 27(D) | 9000901150 | 1 | BEARING; WATER PUMP | 198308 - 199807 | ||
| 27(D) | 9000901150 | 1 | BEARING; WATER PUMP | 199808 - | ||
| 28 | 1136190200 | 1 | WASHER; WATER PUMP | 198308 - 199807 | ||
| 28 | 1136190200 | 1 | WASHER; WATER PUMP | 199808 - | ||
| 29 | 1136310630 | 1 | SHAFT; WATER PUMP | 198802 - 200009 | ||
| 29 | 1136310960 | 1 | SHAFT; WATER PUMP | 200010 - | ||
| 32 | 1136200160 | 1 | SEAL UNIT; WATER PUMP | 198308 - 200009 | ||
| 32 | 8943920900 | 1 | SEAL UNIT; WATER PUMP | 200010 - | ||
| 34 | 9019108180 | 3 | SCREW; COVER TO BODY,WATER PUMP | 198308 - | ||
| 40 | 9098403070 | 1 | NUT; WATER PUMP | 198308 - 199807 | ||
| 40 | 9098403070 | 1 | NUT; WATER PUMP | 199808 - | ||
| 52 | 9091505120 | 6 | WASHER; LK,WATER PUMP | 198308 - | ||
| 57 | 9092045170 | 1 | PLUG; HTR,WATER PUMP | 198308 - | ||
| 66 | 1096254370 | 1 | SEAL; SECONDARY | 198802 - | ||
| 73 | 1093020650 | 1 | STUD; WATER PUMP | 198308 - | ||
| 118 | 9080507220 | 1 | KEY; PULLEY | 198308 - 199807 | ||
| 118 | 9080507220 | 1 | KEY; PULLEY | 199808 - | ||
| 125 | 9991104120 | 1 | NUT; WATER PUMP | 198308 - |
