| Code | Каталожный номер | Qty | Part name | Applied S/N range | ICA | В корзину |
| 1 | 1133140220 | 1 | PIPE; OIL,INJ PUMP TO C/BL | 200510- | |
| 002(A) | 1096750770 | 3 | BOLT; EYE,OIL PIPE | 200510-200805 | A |
| 002(A) | 8973722380 | 3 | BOLT; EYE,OIL PIPE | 200806- | |
| 002(B) | 1096750860 | 1 | BOLT; EYE,OIL PIPE | 200510- | |
| 002(C) | 8971499950 | 1 | BOLT; EYE,OIL PIPE | 200510-200711 | A |
| 002(C) | 8980378230 | 1 | BOLT; EYE,OIL PIPE | 200712- | |
| 002(D) | 1096751600 | 1 | BOLT; EYE,OIL PIPE | 200510-200805 | A |
| 002(D) | 8980378260 | 1 | BOLT; EYE,OIL PIPE | 200806- | |
| 003(A) | 1096300840 | 2 | GASKET; EYE BOLT,OIL PIPE | 200510- | |
| 003(B) | 1096300830 | 2 | GASKET; EYE BOLT,OIL PIPE | 200510- | |
| 003(C) | 9095714100 | 2 | GASKET; EYE BOLT,OIL PIPE | 200510- | |
| 003(D) | 1096301410 | 2 | GASKET; EYE BOLT,OIL PIPE | 200510- | |
| 040(A) | 287810250 | 4 | BOLT; OIL PIPE | 200510-200512 | A |
| 040(A) | 287510250 | 4 | BOLT; OIL PIPE | 200601- | |
| 044(A) | 280806350 | 1 | BOLT; CLIP,OIL PIPE | 200510-200512 | A |
| 044(A) | 280506350 | 1 | BOLT; CLIP,OIL PIPE | 200601- | |
| 048(A) | 1097011941 | 1 | CLIP; OIL PIPE | 200510- | |
| 048(B) | 1097011931 | 1 | CLIP; OIL PIPE | 200510- | |
| 063(A) | 8980258870 | 1 | PIPE; OIL,TURBOCHARGER FEED | 200511- | |
| 114(A) | 1133136420 | 1 | PIPE ASM; OIL,BODY | 200511- | |
| 117 | 9095714101 | 4 | GASKET; JOINT,OIL PIPE | 200510- | |
| 132 | 8980274410 | 1 | PIPE ASM; OIL,INJ PUMP FEED | 200510- | |
| 146 | 280808160 | 2 | BOLT; BRACKET | 200510-200512 | A |
| 146 | 280508160 | 2 | BOLT; BRACKET | 200601- | |
| 147 | 8943993990 | 1 | GASKET; OIL PIPE TO TURBOCHARGER | 200510- | |
| 149(A) | 1133140610 | 1 | PIPE; OIL RETURN,TURBOCHARGER | 200511- | |
| 150 | 1096234500 | 1 | GASKET; OIL PIPE TO C/BL | 200510- | |
| 157 | 8980274750 | 1 | BRACKET; OIL PIPE | 200510- | |
| 204 | 1097008391 | 1 | CLIP; OIL PIPE | 200510- | |
| 205 | 280808120 | 1 | BOLT; CLIP | 200510-200512 | A |
| 205 | 280508120 | 1 | BOLT; CLIP | 200601- | |
| 315 | 1096232990 | 1 | GASKET; OIL FILLER | 200510- | |
| 384(A) | 1133452270 | 1 | BRACKET; CLIP,OIL PIPE,TURBOCHARGER | 200510- | |
| 404 | 287810200 | 1 | BOLT; BRKT | 200510-200512 | A |
| 404 | 287510200 | 1 | BOLT; BRKT | 200601- | |
| 449 | 9095714102 | 2 | BOLT; OIL FILLER | 200510-200512 | A |
| 449 | 9095714103 | 2 | BOLT; OIL FILLER | 200601- | |
