Code | Каталожный номер | Qty | Part name | Applied S/N range | ICA | В корзину |
016(A) | 1097003291 | 1 | CLIP; HARNESS | 200510- | ||
016(B) | 1097008590 | 1 | CLIP; HARNESS | 200510- | ||
016(C) | 1097008600 | 2 | CLIP; HARNESS | 200510- | ||
016(D) | 1097008610 | 1 | CLIP; HARNESS | 200510- | ||
016(E) | 1097009940 | 1 | CLIP; HARNESS | 200510- | ||
016(F) | 1097009951 | 1 | CLIP; HARNESS | 200510- | ||
016(G) | 1097010120 | 3 | CLIP; HARNESS | 200510- | ||
016(H) | 5097003480 | 1 | CLIP; HARNESS | 200510- | ||
016(I) | 1097008480 | 2 | CLIP; HARNESS | 200707- | ||
016(J) | 9095258360 | 4 | CLIP; HARNESS | 200510-200606 | A | |
016(J) | 952358360 | 4 | CLIP; HARNESS | 200607- | ||
053(A) | 1474655180 | 1 | BRACKET; HARNESS | 200510-200811 | ||
053(A) | 9095258361 | 2 | BRACKET; HARNESS | 200812- | ||
053(B) | 1474758680 | 1 | BRACKET; HARNESS | 200510- | ||
053(C) | 8976028701 | 1 | BRACKET; HARNESS | 200510- | ||
139(A) | 280808200 | 1 | BOLT; BRKT | 200510-200512 | A | |
139(A) | 280508200 | 1 | BOLT; BRKT | 200601- | ||
139(B) | 281810160 | 1 | BOLT; BRKT | 200510-200512 | A | |
139(B) | 281510160 | 1 | BOLT; BRKT | 200601- | ||
150(A) | 280808160 | 9 | BOLT; CLIP | 200510-200512 | A | |
150(A) | 280508160 | 9 | BOLT; CLIP | 200601- | ||
150(B) | 9095258362 | 5 | BOLT; CLIP | 200510-200512 | A | |
150(B) | 9095258363 | 5 | BOLT; CLIP | 200601-200706 |
